Metallic Double Bubble Wrap Insulation Materials Aluminium Bubble Foil Insulation For Roof   Our's Reflective Foil Thermal Insulation Material 1.Reflects up to 97% of radiant energy, 2.Inhibits condensation and resists growth of fungi, mold and mildew 3.Fireproof Bubble Insulation Material-Class A/Class 1 fire rating 4.Safe for the environment 5.Stable and durable; does not disintegrate over time 6.Non-toxic and non-carcinogenic for a safe and healthy home during   Foil Bubble Insulation Tengen 's Insulation reflects thermal rays retaining heat or alternatively keeping living spaces cool. Insulation provides an insulating barrier between interior and exterior environments protecting against Cold, Heat and UV Light . The surface adopts aluminum film insulation layer with 97% heat radiation blocking rate, the middle adopts nano airbag layer to form buffer heat convection, and the bottom layer adopts round aluminum film insulation with secondary heat reflection, enhancing its overall thermal capabilities.

  Our foam foil insulation is light weight, easy to handle rolls that will not blow away or break up in the wind. Foam foil insulation have a wide used in daily life, provides cost effective, high efficiency performance. Thermal insulation material is versatile in use for residential, commercial and agriculture such as covers the roofs, ceilings, crawl spaces, wall and attics and even utilize for packaging purposes.   1) 1 layer of polyethylene EPE / XPE foam that is sandwiched between two aluminum foils, low emissivity surfaces. 2) The polyethylene encapsulated air bubbles serve as an effective thermal break as well as a vapor barrier while the two outer surfaces reflect up to 97% of all radiant energy.     Typical Physical Properties Thickness 4-8mm Length 5m, 10m, 25m, 40m etc customized Width 1.2m / 1.5m Sqms/Roll 6 sqm / 12sqm / 30sqm / 48sqm Reflectivity 97% Emissivity 0.03 Water proof 100% Fire proof Class A Application Temperature -50ºC~80ºC MOQ 3000 Square Meters   Advantages Environmental protection, soft and lightweight No odor and toxicity, environmentally- friendly,energy-saving ; Cuts and installs easier than fiber glass; Cost-effective; In most cases Easy & quicker to install than traditional fibre products Keep warm in winter, hold cool in summer Reflecting up to 97% of radiant heat Compliance with the latest insulation standards Heat preservation and energy saving Excellent fire properties

Types / Structures Optionals 1 MPET + EPE / XPE foam 2 MPET + EPE / XPE foam + MPET 3 Alu + EPE / XPE foam 4 Alu + EPE / XPE foam + Alu 5 Alu + woven + EPE / XPE foam + Alu 6 Alu + woven + EPE / XPE foam + woven + Alu 7 Alu + woven + EPE / XPE foam + Alu + Anti-glare coating 8 Alu + (single / double) PE bubble + EPE / XPE foam+ woven + Alu + Anti-glare coating   Applications * Heat Insulation: Building Thermal Insulation Material to reduce summer heat and keep warm in winter. * Covers: It can be heat sealed to be roof cover to reflect heat radiation and seal airtight. * Wrapping: Protective coating of ventilating pipe, HVAC Duct & Pipe or To make Bubble mailer, Bag
